Convertible






CONVERTIBLE






1. Remove door trim panel and water dam.

2. Disconnect wire connector to power window motor.

3. Remove nuts (5) attaching regulator lift channel to door glass.

4. Secure door glass in upward position.

5. Remove nuts (5) attaching rear of stabilizer channel to door panel.

6. Remove stabilizer channel from door panel.

7. Loosen bolts attaching window regulator, base plate to door inner panel.

8. Remove window regulator through large hole in inner door panel.

9. Remove power window motor from regulator.
