Removal

REMOVAL

1. Open liftgate.

2. Remove liftgate CHMSL access panel.

3. Disconnect the rear washer hose at nozzle.

4. Remove the nut retaining the rear washer nozzle and remove the nozzle from rear window glass and vehicle.
