Cruise Control Vacuum Reservoir: Service and Repair

Vacuum Reservoir Location:




The vacuum reservoir is attached to the right-inner fender located below the right headlamp.

REMOVAL
1. Remove right headlamp assembly.
2. Disconnect vacuum line at reservoir.
3. The reservoir is attached with one bolt (upper). The lower ear at bottom of reservoir fits into an access slot on fender support. Remove mounting bolt and remove reservoir from vehicle.

INSTALLATION
1. Fit lower reservoir mounting ear into access slot on fender support.
2. Install upper bolt and tighten to 4 Nm (35 in. lbs.) torque.
3. Install vacuum line at reservoir.
4. Install right headlamp assembly.
