Installation
INSTALLATION 1.
Apply Mopar Lock AND Seal or equivalent to new flywheel bolts.
2.
Install
flywheel (1) on engine crankshaft (2) and install flywheel bolts.
3.
Tighten
flywheel (1) bolts in sequence to 75 Nm (55 ft. lbs.).
4.
Install clutch assembly (1) onto the
flywheel (2). Install clutch housing and transmission
TR6060 Manual Transmission - Installation.
