Ignition Coil: Locations
Top Front Of Engine.:
At Distributor
Applicable to: V8-351/5.8L Engine
LH Side Of Engine.:
At Distributor
Applicable to: 1981 V8-302/5.0L & V8-351/5.8L Engines
LH Side Of Engine.:
At Distributor
Applicable to: 1984-85 6-300/4.9L Engine (Over 8500 Lbs. GVW)
LH Side Of Engine.:
At Distributor
Applicable to: 1982-83 V8-302/5.0L & V8-351/5.8L Engines w/EEC
LH Side Of Engine.:
At Distributor
Applicable to: 1984-85 V8-460/7.5L Engine
LH Side Of Engine.:
At Distributor
Applicable to: 1981 6-300/4.9L Engine w/MCU
RH Side Of Engine.:
At Distributor
Applicable to: 1981 V8-302/5.0L & V8-351/5.8L Engines w/EEC
RH Side Of Engine.:
At Distributor
Applicable to: 1981 V8-351M/5.8L & V8-400/6.6L Engines
RH Side Of Engine.:
At Distributor
Applicable to: 1982 V8-351M/5.8L & V8-400/6.6L Engines
LH Side Of Engine.:
At Distributor
Applicable to: 1982-83 6-300/4.9L Engine w/MCU
Top RH Side Of Engine.:
At Distributor
Applicable to: 1982-83 V8-302/5.0L & V8-351/5.8L Engines w/EEC
LH Side Of Engine.:
At Distributor
Applicable to: 1982-83 V8-255/4.2L & V8-302/5.0L Engines
RH Side Of Engine. 5.0 5.8:
At Distributor
Applicable to: 1984-85 V8-351/5.8L & Carbureted V8-302/5.0L Engines w/EEC-IV (Under 8500 Lbs. GVW)
RH Side Of Engine.:
At Distributor
Applicable to: 1985 V8-351/5.8L Engine w/4 Barrel Carb. Except Calif.
RH Side Of Engine.:
At Distributor
Applicable to: 1985 V8-460/7.5L Engine w/Manual Trans.
LH Side Of Engine.:
At Distributor
Applicable to: 1985 6-300/4.9L Engine w/EEC IV (Under 8500 Lbs. GVW)
