Engine - Surging On Acceleration/Steady Speeds

87ford01

Article No. SURGE -4.9L - DURING ACCELERATION AND/OR
87-13-27 STEADY HIGHWAY SPEEDS - VEHICLES WITH
AUTOMATIC TRANSMISSION

LIGHT TRUCK: 1987 F-250 HD, F-350, E-350

CALIBRATION: 7-72J-R00


ISSUE: Surging during acceleration and/or at steady highway speeds may be caused by the vehicle calibration running too lean. This condition occurs on vehicles with less than 1000 miles/1600 kilometers.

ACTION: To correct this, change the vehicle calibration to 7-72J-R10 by installing a new level EEC IV processor (E7TZ-12A650-BLD).

Authorized Modifications Decal:

Obtain an Authorized Modifications Decal and list the date, dealer number, and summary of alterations performed. Select a prominent place adjacent to the Vehicle Emission Control Information Decal suitable for installing the Authorized Modifications Decal. Clean the area, install the decal, and cover it with a clear plastic decal shield.


PART NUMBER PART NAME CLASS

E7TZ-12A650-BLD EEC IV Processor B

OTHER APPLICABLE ARTICLES: None
WARRANTY STATUS: Reimbursable within the provisions of the Warranty and Policy Manual
OPERATION: SP871327A
TIME: 0.9 Hr.
DLR. CODING: Basic Part No. DRIVE - Code: M3
