ISC Actuator Pinpoint Test K - Manual Revision


90ford11
ENGINE/EMISSIONS DIAGNOSIS SHOP MANUAL REVISION - 1988 - PAGE 19-170 - IDLE SPEED CONTROL ACTUATOR CONNECTOR PIN DIAGRAM REVISED

Article No. 90-6B-11







FORD: 1988 ESCORT, TAURUS


ISSUE: The Idle Speed control Actuator (ISCA) connector pin diagram in Pinpoint Test KB is incorrect. The affected information is on page 19-170 of the 1988 Engine Emissions Diagnosis Shop Manual.

ACTION: Refer to the pages following this TSB article for the revised information and diagram.

OTHER APPLICABLE ARTICLES: None
WARRANTY STATUS: INFORMATION ONLY
OASIS CODES: 2800
