Blower Motor: Service and Repair

Fig. 26 Disconnecting blower motor wire connectors:

1. Disconnect battery ground cable.
2. Disconnect wire connector from blower motor.
3. Remove air cleaner.
4. Remove three solenoid box cover bolts, Fig. 26.
5. Disconnect blower motor cooling tube at blower motor.
6. Remove three blower motor to housing attaching screws and remove motor and wheel assembly.
7. Reverse procedure to install.
