Switch Connecting Wire Repair
Removal and Installation 1.
On driver's door, remove nut from outside rear view mirror control switch.
2.
Gently pry up front portion of switch housing.
3.
Gently pry up sides and rear of switch housing from armrest cavity.
4.
Disconnect switch connections and remove switches.
5.
To install, reverse Removal procedure.
