System Specifications

General Torque Specifications


























Cylinder Head Tightening Specifications

CAUTION: The bolts are torque-to-yield, new bolts must be installed or engine damage may occur.






Install the cylinder head and tighten the bolts in three stages using the sequence shown.

^ Stage 1: Tighten the bolts to 20 Nm (15 ft. lbs.).
^ Stage 2: Tighten the bolts to 40 Nm (30 ft. lbs.).
^ Stage 3: Tighten the bolts an additional 90 degrees.
