Overhead Console Reading Lamp Assembly
REMOVAL 1.
Remove the overhead console assembly.
2.
Separate the reading lamp assembly from the console.
1
Remove the eight screws.
2
Release the electrical connector.
3
Separate the reading lamp assembly.
3.
Remove the storage bin doors.
1
Remove the four screws.
2
Remove the storage bin doors.
INSTALLATION 1.
To install, reverse the removal procedure.
