Stabilizer Bar: Service and Repair

Stabilizer Bar

Removal and Installation
1. Remove the LH wheel and tire.





2. Remove the two stabilizer bushings.
1. Remove the four bolts.
2. Remove the two stabilizer bushings.





3. Remove the stabilizer bar.
1. Remove the two stabilizer bar links lower nut.
2. Remove the stabilizer bar.
4. To install, reverse the removal procedure.
