Home >> Ford >> 2004 >> Expedition 2WD V8-5.4L SOHC VIN L >> Repair and Diagnosis >> Transmission and Drivetrain >> Automatic Transmission/Transaxle >> Specifications >> Mechanical Specifications >> 4R70W Automatic Transmission >> Band/Clutch Application Chart B

Band/Clutch Application Chart B

Band/Clutch Application Chart B

Part 1:




Part 2:
