Torque Specifications

Torque Specifications

Torque Specifications:

Torque Specifications:

Torque Specifications:

Torque Specifications:

Rod Bearing Cap Bolts





Stage 1: 43 Nm (32 ft. lbs.)
Stage 2: additional 105 degrees
