Power Window Switch: Service and Repair
Window Control SwitchRemoval and InstallationNOTE: LF shown, all others similar.
1.
Remove the door trim panel.
2.
NOTE: There are 2 tabs on the opposite side not shown in the illustration.
Unlock the 4 tabs and remove the window control switch from the door trim panel.
3.
To install, reverse removal procedure.
