Output Shaft Speed (OSS) Sensor

Output Shaft Speed (OSS) Sensor









Removal and Installation

1. With the vehicle in NEUTRAL, position it on a hoist.

2. Disconnect the Output Shaft Speed (OSS) sensor electrical connector.

3. Remove the OSS (Output Shaft Speed) sensor bolt and sensor.
- Remove the OSS (Output Shaft Speed) sensor bolt.

- Remove the OSS (Output Shaft Speed) sensor.


4. To install, reverse the removal procedure.
- Tighten bolt to 12 Nm (106 lb-in).
