Rear Seat Back Cushion Frame Replacement (Suburban/Yukon XL)

Rear Seat Back Cushion Frame Replacement (Suburban/Yukon XL)

Removal Procedure




1. Remove the seat back trim cover (1) and the pad (7).
2. Remove the latch release cable.

Installation Procedure

1. Install the latch release cable.




2. Install the seat back trim cover (2) and the pad (12).
