Battery Negative Cable Replacement

Battery Negative Cable Replacement (6.6L)

Removal Procedure

Caution: Refer to Battery Disconnect Caution.




1. Disconnect the negative battery cable.
2. Remove the negative battery cable clip (1) from the positive and negative cable bracket.
3. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle.
4. Remove the engine wiring harness ground bolt (3).
5. Reposition the engine wiring harness ground (4) and remove the negative battery cable (2) from the engine block.




6. Lower the vehicle.
7. Remove the negative battery cable from the vehicle.

Installation Procedure




1. Install the negative battery cable to the vehicle.
2. Raise the vehicle.




3. Position the negative battery cable (2) to the engine block and position the engine wiring harness ground (4) on top of the negative battery cable terminal.

Notice: Refer to Fastener Notice.

4. Install the engine wiring harness ground bolt (3).

Tighten to bolt to 25 N.m (18 lb ft).

5. Lower the vehicle.
6. Install the negative battery cable clip (1) to the positive and negative cable bracket.
7. Connect the negative battery cable.
