P2761
DTC P2761
Circuit Description
The torque converter clutch (TCC) pressure control solenoid (PCS) is a pressure proportional to current (PCC) solenoid used to control the TCC apply and release. The transmission control module (TCM) provides voltage to the main modulation (MAIN MOD), TCC and pressure control solenoid 1 (PCS1) through a separate solid-state device called high side driver 1 (HSD1). The TCM regulates the amount of current to the TCC PCS by switching the low side driver ON and OFF.
DTC P2761 is a type A DTC.
DTC Descriptor
This diagnostic procedure supports the following DTC:
DTC P2761 Torque Converter Clutch (TCC) Pressure Control Solenoid (PCS) Control Circuit Open
Conditions for Running the DTC
* DTC P0716, P0717, P0721 and P0722 are not active.
* The components are powered and ignition voltage is greater than 9.0 volts and less than 18 volts.
* TCM initialization is in process or engine speed is greater than 200 RPM and less than 7,500 RPM for 5 seconds.
* The TCC is commanded ON.
Conditions for Setting the DTC
DTC P2761 sets when the TCM detects an open circuit on the TCC PCS return circuit for greater than 6 seconds.
Action Taken When the DTC Sets
* The TCM illuminates the malfunction indicator lamp (MIL).
* If the failure occurs while in a forward range, a shift to 1st, 3rd or 5th range is made.
* While diagnostic response is active, if the shift selector is moved to NEUTRAL, the transmission will shift to NEUTRAL. If the shift selector is moved to REVERSE, the transmission will shift to REVERSE. If the shift selector is moved to a forward range or to REVERSE and the transmission is compromised by overspeeding or direction change, the transmission will shift to NEUTRAL.
* DTC P2761 is stored in TCM history.
* The TCM inhibits MAIN MOD.
* The TCM inhibits REVERSE operation.
* The TCM freezes shift adapts.
* The TCM inhibits TCC engagement.
Conditions for Clearing the MIL/DTC
A scan tool can clear the code from TCM history. The TCM automatically clears the DTC from TCM history if the vehicle completes 40 warm-up cycles without failure.
Diagnostic Aids
* Inspect the wiring for poor electrical connections at the TCM. Inspect for the following conditions:
- A bent terminal
- A backed-out terminal
- A damaged terminal
- Poor terminal tension
- A chafed wire
- A broken wire inside the insulation
* When diagnosing for an intermittent short or open, massage the wiring harness while watching the test equipment for a change.
* You may have to drive the vehicle in order to experience a condition.
* DTC P2761 set in combination with DTC P0960 and P2727 may indicate an open in the HSD circuit.
