Power Mirror Motor: Service and Repair
Power Mirror Actuator Replacement 1.
Remove the mirror holder.
2.
Remove the three mounting screws from the actuator. (A).
3.
Disconnect each connector (B) and remove the actuator (C).
4.
Install the actuator in the reverse order of removal.
