Windshield Washer Hose: Service and Repair

Washer Tube Replacement

Windshield and Rear Window

1. Remove the right front inner fender Front Inner Fender Replacement.

2. Remove the washer nozzles and clips, then remove the washer tubes.

Front





Rear





3. Install the new parts in the reverse order of removal. Take care not to pinch the washer tubes. Check the washer operation.
