A/T - Overdrive Switch Circuts W or W/0 Cruise Control
89hyundai04
Subject:
OVERDIRVE SWITCH CIRCUIT W & WO CRUISE CONTROL
Group:
TRANSMISSION/DRIVELINE
Number:
007
Date:
MAY, 1989
Model:
SONATA
OVERDRIVE SWITCH CIRCUITS:
There are two different overdrive switch circuits, one for vehicles equipped with the factory installed cruise control option and one for vehicles without that option.
