Tightening Torque Specifications
Part 1 Of 2:
Part 2 Of 2:
TIGHTENING TORQUE SPECIFICATIONS HEAD BOLT TIGHTENING SEQUENCECAMSHAFT BEARING CAP BOLT TIGHTENING SEQUENCE Tighten the bearing caps to the specified torque in two or three steps as shown.
Tightening torque:
Bearing cap bolt:
10-12 Nm (140-150 kg.cm, 10-11 ft. lbs.)
