Ignition Lock: Testing and Inspection

INSPECTION OF CLUTCH START SYSTEM (IGNITION LOCK SYSTEM)




CHECK CLUTCH PEDAL
Check that pedal height, pedal freeplay and clutch pedal clevis pin play are correct.

Ignition Lock Switch:
