Camshaft Bearing Cap Torque & Sequence








Tighten the bearing caps to the specified torque in two or three steps as shown.
Tightening torque
Bearing cap bolt: 14 - 15 Nm (140 - 150 kg.cm, 10 - 11 ft. lbs.)
