Combination Switch: Testing and Inspection

INSPECTION
Check the continuity between the terminals while operating the switch.

Lighting Switch [MO1-2]:






Dimmer And Passing Switch (Connector No.: M 10-2):






Turn Signal And Lane Change Switch [M01-2]:






Wiper Switch (Connector No.: M 10-1):






Wiper Switch (Connector No.: M 10-1):






Rear Wiper And Washer Switch [MO1-1]:
