Component Inspection
EngineEngine Control - P0117 Engine Coolant Temperature Circuit Low Input Component InspectionComponent InspectionCheck ECTS resistance 1.
IG "OFF" and disconnect ECTS connector.
2.
Measure resistance between signal and ground terminals of ECTS connector after checking out the temperature of ECTS with scantool. (Component Side)
Specification : 3.
Is the measured resistance within specification?
