System Inspection
EngineEngine Control - P0562 System Voltage Low System InspectionSystem InspectionCheck Generator circuit 1.
Engine starts.
2.
Maintain ENG RPM 2,500 RPM over 2 minutes.
3.
Measure voltage between the battery terminal (+) and the battery terminal (-).
Specification : Approx. 12.5 - 14.7 V 4.
Is the measured voltage within specification?
