Component Inspection





Engine

Engine Control - P0564 Cruise Control Multi-Function Input A Circuit Component Inspection

Component Inspection

Check auto cruise switch
1. IG "OFF" and disconnect Cruise switch connector.
2. Measure resistance between signal and ground terminals of Cruise switch connector with 'RESUME' switch depressed. (Component side)
3. Measure resistance between signal and ground terminals of Cruise switch connector with each switch depressed. (Component side)
Specification :









4. Is the measured resistance within specification?
