Valve Guide - Diameter





VALVE GUIDE
Valve guide hole diameter (for service parts):
Intake & Exhaust .............10.175 - 10.196 mm (0.4006 - 0.4014 inch)


Finished size:
Intake & Exhaust..............6.000 - 6.018 mm (0.2362 - 0.2369 inch)
