Navigation Module: Description and Operation
NAVI Control UnitThe gyro (angular speed sensor) and the CD-ROM drive are built-in units that control the navigation functions.
Signals are received from the gyro, the vehicle speed sensor, and the GPS antenna. Vehicle location is determined by combining this data with the data contained in the CD-ROM map. Locational information is shown on liquid crystal display panel.
