Supplemental Restraint System (SRS)

SIR Symbol:

The Supplemental Restraint System(SRS) symbol is used on schematics to alert the technician to the following important caution.

CAUTION: This vehicle is equipped with SRS. Refer to CAUTIONS in SRS under Air Bags and Seat Belts before performing service on or around SRS components or wiring. Failure to follow CAUTIONS could result in possible air bag deployment, personal injury, or otherwise unneeded SRS system repairs.
