Solar Sensor: Service and Repair
Removal and Installation -
Disconnect battery earth lead.
-
Carefully pry the assembly solar/alarm sensor from the fascia.
-
Disconnect the sensor multi-plug connector and remove the sensor assembly.
NOTE: -
Installation is the reverse of this procedure.
-
This unit is NOT serviceable.
