Connecting Rod Bearing Availability
Fig. 14 Connecting rod bearing selection chart. V8 engines:
The
connecting rod journal is identified by a color coded paint mark on adjacent cheek or counterweight toward flanged (rear) end of
crankshaft. Color codes used to indicate journal sizes and corresponding bearing sizes are listed in
Fig. 14.
