Home >> Jeep >> 1983 >> Cherokee L6-258 4.2L VIN C 2-bbl >> Repair and Diagnosis >> Powertrain Management >> Diagrams >> Electrical Diagrams >> System Schematics

System Schematics

Fig. 9 CEC system Wiring circuit. 1983 6-258/4.2L:
