Manual Transmission/Transaxle: Application and ID
Fig. 2:
The AX5 identification code is on the bottom surface of the transmission case near the fill plug. The first number is year of manufacture. The second and third numbers indicate month of manufacture. The next series of numbers is the transmission serial number.
