Automatic Transmission/Transaxle

SCHEMATICS AND DIAGRAMS


Hydraulic Flow In Park/Neutral:




Hydraulic Flow In D-First Gear:




Hydraulic Flow In D-Second Gear:




Hydraulic Flow In D-Third Gear:




Hydraulic Flow In D-Third Gear (Converter Clutch Applied):




Hydraulic Flow At Part Throttle 3-2 Kickdown:




Hydraulic Flow At Full Throttle 3-2 Kickdown:




Hydraulic Flow In Manual Second:




Hydraulic Flow In Manual Low:




Hydraulic Flow In Reverse:
