Air Inlet Screen Installation
SCREEN-AIR INLETNOTE: LHD model shown. RHD model similar. 1.
Position the air inlet screen (1) into the cowl panel (3) and fully engage the screen onto the two retaining studs (4).
2.
Install the air inlet screen onto the cowl panel and install the two retaining nuts (4). Tighten the nuts to 2.3 Nm (20 in. lbs.).
3.
Install the cowl grille
Cowl Panel Cover - Installation.
