Shift Interlock Cable: Adjustments

ADJUSTMENTS










1. Remove floor console as necessary for access to the park-interlock cable.
2. Make sure the shifter is in PARK position.
3. Un-snap the cable end fitting from shifter base reaction bracket.
4. Attempt to take out the key from ignition cylinder moving the core cable fore/aft.
5. With the key removed from cylinder, un-snap the locking tab from cable end-fitting.
6. Slide back in the cable end-fitting onto shifter base reaction bracket.
7. Push in the locking tab until fully seated - the top surface must be under flash relatively to cylinder end-fitting and both sides snapped over the locking features.
8. Verify proper operation.
9. Install the floor console.
