Differential Assembly: Tools and Equipment

SPECIAL TOOLS

D-115-3 - Arbor

C-293-48 - Block Set, Puller

C-293-47 - Block Set, Puller

6739 - Block, Height

D-115-2A - Block, Scooter

8926-2 - Button, Press Adapter

6740 - Cone

C-4171 - Driver Handle, Universal

8540 - Gauge, Pinion Height

C-4735 - Handle, Driver

6310-9 - Head

C-3281 - Holder, Flange

6448A - Installer, Bearing/Gear

C-4198 - Installer, Axle Bearing

C-4340 - Installer, Bearing

C-4308 - Installer, Bearing Cup

D-130 - Installer, Bearing Cup

C-3718 - Installer, Flange

8493 - Installer, Seal

C-4076-B - Installer, Seal

8976 - Pinion Driver

10126-2 - Pins, Guide

C-293-PA - Puller, Press

C-4345 - Remover, Bearing Cup

C-4307 - Remover, Bearing Cup

6310 - Remover, Bearing/Seal

8992 - Remover, Pinion Flange

10126-1 - Remover, Ring Gear

6741 - Screw

8541A - Set, Arbor Disc

C-3339A - Set, Dial Indicator

C-4164 - Wrench, Differential Preload
