Vehicle Speed Sensor: Testing and Inspection
Vehicle Speed Sensor-Circuit Testing:
1.
Remove the instrument cluster.
2.
Check continuity between terminals C230/3 (GRN/RED) and C229/14 (BLK) while rotating the speedometer cable shaft.
3.
If there are not four pulses per shaft rotation, replace the
vehicle speed sensor.
