Symptom Related Diagnostic Procedures





Master Power Window Switch will not Operate Other Windows A

Preliminary Check: Verify that the master power window switch operates drivers window. If it does not, first perform procedure for None of the Power Windows Operate.





Individual Door Switch Does Not Operate, but Master Switch Operates

Preliminary Check: Verify that lock out switch is in the OFF (up) position, that the drivers window operates all of the other windows. If they do not operate, first perform procedure for None of the Power Windows Operate.
