Torque Specifications
Cylinder Head Bolt Tightening Sequence:
Cylinder Head Bolts Tightening Torque
59 - 64 ft. lbs. (80 - 87 Nm) Follow the pattern shown, and tighten in 3 equal steps.
Main Bearing Cap Bolts Tighten the caps in two or three steps in the order shown in the figure
Tightening Torque:
61 - 65 ft. lbs. (82 - 88 Nm)
