Data Link Connector: Locations
No.
Description
9.
Remove 4 screws securing fusebox cover to centre console.
10.
Remove cover.
C40-Diagnostic Connector:
C40 DIAGNOSTIC CONNECTOR 16 Way Female BLACK Behind front of center console
A diagnostic connector, located below the passenger compartment fuse box, allows engine tuning or fault diagnosis to be carried out using TestBook.
