Tow Sensor: Service and Repair
Inclination SensorRemoval 1.
Remove the generic electronic module (GEM).
2.
Remove the inclination sensor.
^
Disconnect the electrical connector.
Installation 1.
Install the inclination sensor.
^
Connect the electrical connector.
2.
Install the GEM.
3.
Using the Land Rover approved diagnostic equipment, follow the on-screen instructions and configure the inclination sensor.
