Control Assembly: Service and Repair





Climate Control Assembly

Removal

NOTE:
Removal steps in this procedure may contain installation details.

NOTE:
Some variation in the illustrations may occur, but the essential information is always correct.

NOTE:
Make sure that the gear selector lever is in position N before removing any components.




1




2




3




4




5




6




7




8




9





10





11





12





13





14





15

Installation
1 To install, reverse the removal procedure.
