Cruise Main Indicator Light Circuit

CRUISE MAIN INDICATOR LIGHT CIRCUIT

CIRCUIT DESCRIPTION
Output the cruise control controlling condition and the diagnosis code from the ECM to the combination meter. This signal is transmitted to the combination meter by BEAN signal.
