Oil Separator: Service and Repair
REMOVAL 1.
Remove the LH cylinder head. For additional information, refer to Engine.
2.
Remove the bolts and the
oil separator. Discard the gasket.
INSTALLATION 1.
To install, reverse the removal procedure.
^
Install a new gasket.
