Crankshaft Position Sensor 2
View: Crankshaft Position Sensor 2 Test Connections:
CRANKSHAFT POSITION SENSOR 2 1.
Unplug sensor connector.
2.
Measure resistance between terminals A and B. It should be
520 - 580 ohms @ 68°F (20°C). 3.
If not as specified, replace sensor.
