Pinpoint Test 8
PINPOINT TEST 8: THE BLOWER MOTOR OPERATES CONTINUOUSLY IN HIGH SPEEDStep 1 - 2:
Normal OperationWhen the
blower motor switch is placed in high and the function selector switch is in any position except OFF, the blower motor switch creates a direct link to ground for the
blower motor, resulting in high speed operation.
Possible Causes -
blower motor switch -
circuit (O/B) open
